Cone 10 Glossy Transparent Base| Code | G1947U |
| Modification Date | 2011-12-07 12:56:56 |
| Description | Reliable widely used base |
Recipe| Material | Amount | Units | +/- | *Stat |
| Custer Feldspar | 27.00 | g | | |
| EPK | 20.50 | g | | |
| Silica | 26.50 | g | | |
| Wollastonite | 23.50 | g | | |
| Zinc Oxide | 2.50 | g | | |
| | 100.00 | |
Firing Schedule
| Rate (C) | Temp (C) | Hold (Min) | Step | | ~10 pilots | 100 | 0 | 1 | | 50 | 550 | 0 | 2 | | 100 | 980 | 0 | 3 | | 50 | 1300 | 0 | 4 | | 0 | 1300 | 30 | 5 | | Freefall | 30 | | 6 |
NotesThis was used as a high temperature porcelain insulator glaze on a 25-Porcelain body. It works well not only as a transparent, but as a base from which to make a range of different colors.
1-40
